UTILITY BOAT

Name of vessel :

AFRICAN STAR 2

GT :

290

Type :

Utility boat

NT :

87

Owners :

OK SHIPPING LTD Kingstown

Deadweight :

255.9 mt

Flag :

St Vincent & The Grenadines

Operational DWT :

136.0 mt

Port of Registry :

Kingstown

Light weight :

101.7 mt

Official Number :

6726

Deck cargo :

80 mt

Call Sign :

J8LS8

Main deck area :

120 m²

IMO Number :

8888135

Length o.a. :

41.15 m

Satcom C :

0584 4376 003 85

Beam, moulded :

8.56 m

Builder's Yard :

EQUITABLE SHIPYARD Inc.
New Orleans La, U.S.A.

Depth (midship) :

3.44 m

Year built :

11/1995

Draught :

2.71 m

Hull No. :

369

Marine Gas Oil :

89.8 m³

Classification :

Bureau Veritas

Fresh water :

29.7 m³

Class Notation :

I 3/3 E MACH

Ballast capacity :

44.3 m³

B.V. Number :

962V27

Container cap. :

6 TEU

Main engines :

5 diesel engines, Cummins, KTA 19-M3, directly coupled via reduction/
reversing gear-boxes to 5 FP-propellers

Power, nominal :

5 x 600 BHP at 1800 RPM = total 3000 BHP

Speed :

About 17.3 knots

Generators :

2 diesel generators, Cummins, type 6 BT 5.9-G1 (M), 75 kVA each giving A.C. 3-phase 380/220 V, 50 Hz

Lifting gear :

1 crane, Hiab, type : seacrane 120, capacity : 6.0 mt at 1.7 m, 1.25 mt at 8.3 m

Passengers :

4 Persons (in cabins)

Managers :

ABC Maritime AG
Rue Perdtemps 1
CH-1260 NYON
Switzerland

Tel ( + 41-22) 365 71 00
Fax ( + 41-22) 365 71 11
E-mail: abc@abcmaritime.ch
Tlx 419 907 abc ch

*

On load-line displacement
